Combo SK Duel Fuel
COMBINED Sweeping-Scrubbing-Driyng MODE:
The two powerful counter-rotating brushes, hydraulically controlled, sweep and scrub at the same time all kind of dirt on every kind of surface. The rear V-shaped squeegee collects the dirty water leaving the floor perfectly SWEEPED – SCRUBBED – DRIED – POLLUTION FREE.
SWEEPING MODE:
Sweeping on dry floor, the two powerful counter-rotating brushes collect all kind of dirt and throw it into the back hopper. The dust is then retained by the powerful suction fans in the large filters.
Description
Combo SK Dual Fuel
The last generation of combined machine Combo has been conceived basing on the RCM construction philosophy; the same philosophy followed in the last 50 years to produce ride on sweepers with front driving position, logic driving system, front steering drive wheel to ensure the maximum visibility, manoeuvrability and safety for the operator.
Additional information
| Scrubbing/Sweeping Width | 1655mm |
|---|---|
| Drying Width | 1440mm |
| Solution Tank | 265 litres |
| Recovery Tank | 280 litres |
| Traction | Front Hydrostatic |
| Maximum Working Speed | 10km/h |
| Maximium Speed | 12kph |
| Maximum Gradient | 16% |
| Waste Hopper Capacity | 180L |
| Waste Hopper Unloading | 1560 Hydraulic |
| Filtering Surface | 10mq |
| Dust Filtering Shaker | Electric |
| Engine | Kubota LPG Petrol |
| Installed Power | 41-55kW/Hp |
| Cylinders | 4 |
| Cooling | Water |
| Dimensions (length x width x height) | 2400 x 1540 x 1760 |
| Empty Weight | 1775kg |
Sweeping & Washing
The two counter-rotating roller brushes sweep in an exremely effective wayby retaining the dust and dep washing at the same time by reducing the cleaning hourly rate by 50%.Â
Perfect Drying
The two powerful 3 stages suction motor leave the surfaces perfectly dried and safe preventing from dangerous slippery.Â
Grat Loading CapacityÂ
COMBO features one of the largest hopper of its market segment. If lifts and empties quickly, even into containers up to 1560 mm in height, thus considerably reducing the downtime during unloading procedures.Â
Great Safety
The driving seat located in the front area ensures perfect visibility on both sides, in order to operate completely safely and with top accuracy.Â
Minimum Area for U Turns
Despite its size is that of an industrial machine and if features a wide cleaning track (1350 mm) COMBO can make a U turn between two walls in just 3200 mm.Â
Low Maintenance Costs
Special care has been taken with regard to the accessibility of mechanical components as to reduce maintenance costs. All mechanical components can be reached quickly for inspection and maintenance operations.Â
